BMW X3 G01 (2017-2021) left frontal light electronics left headlight Wiring diagram
This page shows the only wiring diagram for the component.left frontal light electronics left headlight, which is found in the car BMW X3 G01 (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left frontal light electronics left headlight (1 of 1)
BOOSTER
BOTTOM RADIATOR BLIND DRIVE
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
CENTER FRONT PASSENGER DOOR TRIM PANEL LIGHTING
CRASH SAFETY MODULE
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S DOOR SWITCH BLOCK
ELECTRIC FAN
ELECTRIC FAN CUT-OFF RELAY
FROM FUSE 65 (DIAGRAM 4 OF 8)
FRONT PASSENGER EXTERIOR MIRROR
FRONT PASSENGER'S DOOR POCKET LIGHTING
FUSE 217
FUSE 224
FUSE 225
FUSE 226
FUSE 230
FUSE 244
FUSE 67
FUSE 68
FUSE 69
FUSE 70
FUSE 75
HKFM
LEFT FRONTAL LIGHT ELECTRONICS LEFT HEADLIGHT
NATURAL VACUUM LEAK DETECTION
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
REMOTE CONTROL RECEIVER
RIGHT REVERSIBLE ELECTROMOTIVE AUTOMATIC REEL
SIREN W/ TILT ALARM SENSOR
TO REAR POWER DISTRIBUTION BOX (DIAGRAM 3 OF 8)
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TOP FRONT PASSENGER DOOR TRIM PANEL LIGHTING
TOP HIFI AMPLIFIER
TOP RADIATOR BLIND DRIVE
VERTICAL DYNAMICS PLATFORM
WHT/BLU WIRE
Go to component -> Power distribution circuit (5 of 8) -> LEFT FRONTAL LIGHT ELECTRONICS LEFT HEADLIGHT
