BMW X3 G01 (2017-2021) driver's side rear power window switch Wiring diagram
This page shows the only wiring diagram for the component.driver's side rear power window switch, which is found in the car BMW X3 G01 (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's side rear power window switch (1 of 1)
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S SIDE REAR POWER WINDOW SWITCH
FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
FRONT PASSENGER'S DOOR POWER WINDOW SWITCH
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 29
FUSE 67
GRY/BLK WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/
LIN BUS SIG
PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
TERMINAL 30 SPLY
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
