BMW X3 G01 (2017-2021) driver electronic outer door handle module Wiring diagram
This page shows the only wiring diagram for the component.driver electronic outer door handle module, which is found in the car BMW X3 G01 (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver electronic outer door handle module (1 of 1)
2.0L TURBO
BRN WIRE
BRN/WHT WIRE
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
CENTER REAR DRIVER'S SIDE DOOR TRIM PANEL LIGHTING
DRIVER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE
DRIVER EXTERIOR MIRROR
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER SEAT MODULE
DRIVER'S DOOR DOOR POCKET LIGHTING
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S DOOR ENTRY LIGHTING
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
IGNITION COIL CYLINDER 1
IGNITION COIL CYLINDER 2
IGNITION COIL CYLINDER 3
IGNITION COIL CYLINDER 4
INTERIOR REAR LID BUTTON
LEFT REVERSIBLE ELECTROMOTIVE AUTOMATIC REEL
REAR DRIVER SIDE ELECTRONIC OUTER DOOR HANDLE MODULE
REAR DRIVER'S SIDE COURTESY LIGHTING
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
REAR DRIVER'S SIDE ENTRY LIGHT
REAR DRIVER'S SIDE FOOTWELL LIGHT
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TOP REAR DRIVER'S SIDE DOOR TRIM PANEL LIGHTING
Go to component -> Ground distribution circuit (5 of 7) -> DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE
