BMW X3 G01 (2017-2021) bottom front passenger's side instrument panel lighting Wiring diagram
This page shows the only wiring diagram for the component.bottom front passenger's side instrument panel lighting, which is found in the car BMW X3 G01 (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bottom front passenger's side instrument panel lighting (1 of 1)
BLK WIRE
BOTTOM FRONT PASSENGER'S SIDE INSTRUMENT PANEL LIGHTING
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
CENTER DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
DRIVER'S DOOR POCKET LIGHTING
ELECTRIC FAN
FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
INTELLIGENT BATTERY SENSOR
LEFT FRONT FOOTWELL LIGHT
NCA WIRE
ON BATTERY)
PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
TELEMATIC COMMUNICATION BOX
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TOP RADIATOR BLIND DRIVE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Computer data lines circuit (7 of 9) -> BOTTOM FRONT PASSENGER'S SIDE INSTRUMENT PANEL LIGHTING
