BMW X3 G01 (2017-2021) antenna signal amplifier 2 Wiring diagrams

This page contains all the electrical diagrams for the component. antenna signal amplifier 2, in which he is found in the car BMW X3 G01 (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram antenna signal amplifier 2 (1 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (1 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Base radio circuit, w/ active sound design (5 of 5) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (2 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (2 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Base radio circuit, w/o active sound design (4 of 4) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (3 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (3 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Hifi radio circuit, w/ active sound design (6 of 6) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (4 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (4 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Hifi radio circuit, w/o active sound design (5 of 5) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (5 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (5 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Navigation circuit, w/ hifi radio & active sound design (6 of 6) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (6 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (6 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Navigation circuit, w/ hifi radio w/o active sound design (5 of 5) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (7 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (7 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Navigation circuit, w/o hifi radio & active sound design (4 of 4) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (8 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (8 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 BASIC VERSION BASIS BLK WIRE BLU WIRE BLUETOOTH ANTENNA BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY FUSE 214 GRN WIRE GRN/BLU WIRE HEAD UNIT HIGH VERSION HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT LEFT "C" PILLAR) LEFT SIDE WINDOW AERIAL MICROPHONE (W/ TELEMATICS) NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/YEL WIRE USB CONNECTION USED) WHT WIRE WLAN ANTENNA

Go to component -> Navigation circuit, w/o hifi radio w/ active sound design (5 of 5) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (9 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (9 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 ANTENNA SIGNAL AMPLIFIER 3 BLK WIRE BLU WIRE BRN WIRE CARD READER CENTRAL INFORMATION DISPLAY GPS ANTENNA GRN WIRE GRN/BLU WIRE HEAD UNIT INSTRUMENT PANEL LEFT "C" PILLAR) LEFT SIDE WINDOW ANTENNA NCA WIRE ORG/ WIRE REAR SPOILER ANTENNA REAR WINDOW ANTENNA RED WIRE RED/YEL WIRE RIGHT SIDE WINDOW ANTENNA SDARS ANTENNA USB CHARGING SOCKET 3 USB CONNECTION USB PORT WHT WIRE WHT/BLU WIRE

Go to component -> Receiver audio module circuit, base (3 of 3) -> ANTENNA SIGNAL AMPLIFIER 2

Wiring diagram antenna signal amplifier 2 (10 of 11)

Wiring diagram antenna signal amplifier 2 for BMW X3 G01 (2017-2021) (10 of 11)

Get access

ANTENNA SIGNAL AMPLIFIER 2 ANTENNA SIGNAL AMPLIFIER 3 BLU WIRE BRN WIRE FUSE 215 GRN WIRE HEAD UNIT HOT W/ TERMINAL LEFT "C" PILLAR) LEFT SIDE WINDOW ANTENNA MOST DATA BUS CIRCUIT NCA WIRE REAR POWER DISTRIBUTION BOX RED/GRY WIRE RIGHT SIDE WINDOW ANTENNA VIDEO MODULE WHT WIRE

Go to component -> Video system circuit -> ANTENNA SIGNAL AMPLIFIER 2
