Car Wiring Diagrams for Wiper/washer circuit for BMW X3 F25 (2010-2014)

2 1 PT-CAN SIG PT-CAN SIG 23 2 6 21 PWR SUPLY GND PWR SUPLY GND 48 49 K-CAN SIG K-CAN SIG 8 5 12 GND PWR SUPLY PWR SUPLY BASIC VARIANT ROOF FUNCTIONS MODULE BLK WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CENTRAL GATEWAY MODULE (LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTER ELECTRO- CHROMIC INTERIOR REAR-VIEW MIRROR FUSE FUSE 51 FUSE 66 GRN/BLK WIRE GRY/RED WIRE GRY/VIO WIRE HEADLIGHT WASHER PUMP (WASHER FLUID RESERVOIR) HIGH VARIANT ROOF FUNCTIONS MODULE HOT AT ALL TIMES FUSE BOX FUSE 504 (RIGHT REAR COMPT FLOOR BOARD) HOT W/ TERMINAL INSTRUMENT CLUSTER CONTROL UNIT JUNCTION BOX (RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT WASHER NOZZLE HEATED (BOTTOM LEFT OF WINDSHIELD) OUTSIDE TEMPERATURE SENSOR (LEFT FRONT WHEELWELL) RAIN/DRIVING LIGHTS/ CONDENSATION/SOLAR SENSOR REAR WASHER PUMP (WASHER FLUID RESERVOIR) REAR WIPER (LUGGAGE COMPT DOOR) REAR WIPER RELAY RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RIGHT WASHER NOZZLE HEATED (BOTTOM RIGHT OF WINDSHIELD) W/ BASIC VARIANT W/ HIGH VARIANT WASHER FLUID LEVEL SWITCH (WASHER FLUID RESERVOIR) WASHER PUMP RELAY WINDSCREEN WASHER PUMP (RIGHT SIDE OF ENGINE COMPT) WIPER MODULE YEL/BRN WIRE YEL/RED WIRE
