Car Wiring Diagrams for Charging circuit for BMW X3 F25 (2010-2014)

ALTERNATOR BLK WIRE BLU WIRE DIGITAL MOTOR ELECTRONICS CONTROL MODULE (LEFT REAR ENGINE COMPT) 42 42 FRONT POWER DISTRIBUTION BOX (LEFT REAR OF ENGINE COMPT) FUSE BOX FUSE 500 N/A GRN/RED WIRE INTELLIGENT BATTERY SENSOR JUMP START TERMINAL POINT JUNCTION BOX (RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONIC NCA WIRE POWER DISTRIBUTION SYSTEM BATTERY RED WIRE SAFETY BATTERY TERMINAL GENERATOR STARTER TRANSFER TERMINAL POINT VIO WIRE
