Exterior lamps circuit for BMW X3 F25 (2010-2014)

45 43 44 IND LP BRK LT IND LP 5 17 3 25 18 20 GND LIN BUS SIG HIGH BEAM SW GND WARN LT SW SIG LED ACTIVATION 9 40 BRK LT DOOR CONTACT SIG BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/VIO WIRE BRN/YEL WIRE DIRECTION IND FOOTWELL MODULE FUSE 17 FUSE 18 (RIGHT SIDE OF DASH) GRN/BLK WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE HAZARD WARNING LIGHTS SWITCH/ CENTRAL LOCKING BUTTON OPERATING UNIT HOT W/ BISTABLE RELAY ENERGIZED HOT W/ BISTABLE RELAY ENERGIZED JUNCTION BOX (RIGHT SIDE FUSE 13 OF DASH) JUNCTION BOX JUNCTION BOX ELECTRONICS LEFT HEADLIGHT HEADLIGHT DRIVER MODULE LICENSE PLATE LT RR FOG LT TAIL LT BRK LT SW SIG GND LIGHT LIGHT SWITCH UNIT RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT HEADLIGHT HEADLIGHT DRIVER MODULE SERIAL SIG SIDE LIGHTS/ DRL LIGHT SIDE MARKER STEERING COLUMN SWITCH CLUSTER WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/VIO WIRE

AUXILIARY BRAKE LIGHT BLK/WHT WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHT BRAKE LIGHT TAIL LIGHT/ BRK LT RH TURN SIG K CAN-L K CAN-H BRN WIRE BRN/BLK WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM DIRECTION IND DYNAMIC BRAKE DYNAMIC BRAKE LIGHT GRN WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONT DIRECTION INDICATOR REPEATER LIGHT LEFT INNER TAILLIGHT LEFT LICENSE PLATE LIGHT LEFT OUTER TAILLIGHT LIGHT NOISE SUPPRESSOR FILTER ORG/GRN WIRE PREPARATION FOR TRAILER SOCKET RED/BLU WIRE RIGHT FRONT DIRECTION INDICATOR REPEATER LIGHT RIGHT INNER TAILLIGHT RIGHT LICENSE PLATE LIGHT RIGHT OUTER TAILLIGHT TAIL LIGHT/ BRAKE LIGHT TAIL- LIGHT TRAILER MODULE (REAR COMPT FLOOR BOARD) YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/VIO WIRE
