BMW X3 F25 (2010-2014) wake up sig shift paddle Wiring diagram
This page shows the only wiring diagram for the component.wake up sig shift paddle, which is found in the car BMW X3 F25 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wake up sig shift paddle (1 of 1)
3.0L
3.0L TWIN TURBO
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU/RED WIRE
BRN WIRE
CAN BUS SIG CAN BUS SIG CAN BUS SIG CAN BUS SIG
COMPUTER DATA LINES SYSTEM
ELECTRONIC TRANSMISSION CONTROL
FUSE 63
FUSE 64
GEAR SELECTOR SWITCH (CENTER CONSOLE)
GRN WIRE
GRN/RED WIRE
JUNCTION BOX (RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
LEFT SHIFT PADDLE
PNK WIRE
PWR SUPPLY GND
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT SHIFT PADDLE
STEERING COLUMN SWITCH CLUSTER
WAKE UP SIG SHIFT PADDLE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> A/t circuit -> WAKE UP SIG SHIFT PADDLE
