BMW X3 F25 (2010-2014) preparation for trailer socket Wiring diagrams
This page contains all the electrical diagrams for the component. preparation for trailer socket, in which he is found in the car BMW X3 F25 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram preparation for trailer socket (1 of 3)
AUXILIARY BRAKE LIGHT
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE LIGHT
BRAKE LIGHT TAIL LIGHT/
BRK LT RH TURN SIG K CAN-L K CAN-H
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
DIRECTION IND
DYNAMIC BRAKE
DYNAMIC BRAKE LIGHT
GRN WIRE
GRY/BRN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LEFT FRONT DIRECTION INDICATOR REPEATER LIGHT
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT OUTER TAILLIGHT
LIGHT
NOISE SUPPRESSOR FILTER
ORG/GRN WIRE
PREPARATION FOR TRAILER SOCKET
RED/BLU WIRE
RIGHT FRONT DIRECTION INDICATOR REPEATER LIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT OUTER TAILLIGHT
TAIL LIGHT/ BRAKE LIGHT
TAIL- LIGHT
TRAILER MODULE (REAR COMPT FLOOR BOARD)
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> PREPARATION FOR TRAILER SOCKET
Wiring diagram preparation for trailer socket (2 of 3)
BLK WIRE
BLOWER DYNAMIC MOTOR STABILITY CONTROL (DSC)
BRN WIRE
CAR ACCESS SYSTEM UNIT
COMBOX
ELECTRIC FAN CUT OUT RELAY
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE
FROM FUSE 2 (DIAGRAM 2 OF 7)
FROM FUSE 27 (DIAGRAM 2 OF 7) FUSE 14 FUSE 15 FUSE 7 FUSE 8
FROM TERMINAL
FUSE
FUSE 11
FUSE 13
FUSE 16 FUSE 17
FUSE 18
FUSE 19
FUSE 23
FUSE 33
FUSE 58
FUSE 60
FUSE 61
FUSE 71 FUSE 40
FUSE 9 FUSE 37 FUSE 38 FUSE 56
FUSE FUSE
GRN WIRE
HEAD-UP DISPLAY
HEATING/AIR CONDITIONING SYSTEM
HIGH VARIANT ROOF FUNCTION MODULE
HIGH VARIANT ROOF FUNCTIONS MODULE
INSTRUMENT CLUSTER CONTROL GLOVE COMPARTMENT LIGHT
JUNCTION BOX (RIGHT SIDE
JUNCTION FROM BOX FUSE 61 (RIGHT SIDE (DIAGRAM OF DASH) 3 OF 7)
LIGHT SWITCH UNIT
OF DASH)
PARKING BRAKE BUTTON
PREPARATION FOR TRAILER SOCKET
REAR WIPER RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY
SHUTOFF VALVE
SIREN BASIC VARIANT W/ TILT ROOF ALARM FUNCTIONS MODULE SENSOR
STEERING COLUMN SWITCH CLUSTER
TANK VENT
TERMINAL
TO FUSE 32 (DIAGRAM 4 OF 7)
TO TERMINAL
TO WASHER PUMP RELAY (DIAGRAM 4 OF 7)
TRAILER MODULE
TRANSFER CAR ACCESS BOX SYSTEM
VALVE
W/ BASIC VARIANT ROOF FUNCTIONS MODULE
W/ HIGH VARIANT ROOF FUNCTIONS MODULE
W/ TRAILER SOCKET
W/O TRAILER SOCKET
Go to component -> Power distribution circuit (3 of 7) -> PREPARATION FOR TRAILER SOCKET
Wiring diagram preparation for trailer socket (3 of 3)
12 40 IND LP BRK LT
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXTERIOR LIGHTS CIRCUIT
FOOTWELL MODULE
FULLY AUTOMATIC TRAILER TOWING HITCH
FUSE 145
FUSE 19 (RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT W/
HOT W/ BISTABLE RELAY ENERGIZED
JUNCTION BOX
NOISE SUPPRESSOR FILTER
ORG/GRN WIRE
PREPARATION FOR TRAILER SOCKET
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
RH TURN SIG BRK LT
TRAILER MODULE (REAR COMPT FLOOR BOARD)
TRAILER SOCKET
W/ TRAILER MODULE W/O TRAILER MODULE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Trailer tow circuit -> PREPARATION FOR TRAILER SOCKET
