BMW X3 F25 (2010-2014) 44 43 computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.44 43 computer data lines system, which is found in the car BMW X3 F25 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 44 43 computer data lines system (1 of 1)
44 43 COMPUTER DATA LINES SYSTEM
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
CAMERA-BASED DRIVER SUPPORT SYSTEMS CAMERA HEATING
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE CONTROL PANEL
ELECTRONICS JUNCTION BOX
FOOTWELL MODULE
FUSE 13
FUSE 43
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
HOT W/ TERMINAL
JUNCTION BOX (RIGHT SIDE OF DASH)
LANE DEPARTURE WARNING CAMERA (BEHIND INSIDE REARVIEW MIRROR)
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Lane departure warning circuit -> 44 43 COMPUTER DATA LINES SYSTEM
