Trunk & fuel door release circuit for BMW X3 E83 facelift (2006-2010)
Trunk & fuel door release circuit
BLK WIRE
BLU WIRE
BRN WIRE
CENTRAL LOCKING DRIVE, TRUNK LID
FUEL FILLER FLAP CENTER LOCKING DRIVE (ABOVE RIGHT REAR WHEEL)
FUSE
FUSE DISTRIBUTION (RIGHT SIDE OF DASH)
GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH)
GRN WIRE
GRY WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN OR START
POWER
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
TRUNK LID PUSH- BUTTON/ LICENSE PLATE LIGHTS
VIO WIRE
VIO/YEL WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
