Premium radio circuit, top hifi radio for BMW X3 E83 facelift (2006-2010)

ANTENNA AUX-IN CONNECTION AV SOCKET AV SOCKET NAVI + BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE CD AF+ L CD AF+ R CD AF- CD CHANGER COMPUTER DATA LINES SYSTEM DATA (RIGHT SIDE OF LUGGAGE COMPT) COMPUTER LINES SYSTEM FUSE GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH) GROUND ANTENNA LIGHT TERM 30 TERM R GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, ACC OR START K-BUS MUTE LEFT ANTENNA NAVIGATION SYSTEM (LEFT SIDE OF REAR COMPT) NCA WIRE NOISE SUPPRESSOR FILTER POWER DISTRIBUTION (RIGHT SIDE OF DASH) R - L - RADIO RADIO NAVI AV SOCKET SH NAVI - REAR WINDOW RIGHT AERIAL ANTENNA RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE VIDEO MODULE (LEFT SIDE OF REAR COMPT) VIO/WHT WIRE W/ VIDEO MODULE W/ VOICE RECOGNITION SYSTEM W/O VIDEO MODULE W/O VOICE RECOGNITION SYSTEM WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

AF+ RADIO LF MR- LF MR+ RF MR- RF MR+ AMPLIFIER BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/ORG WIRE CD CHGR COMPUTER DATA LINES SYSTEM FUSE 81 (CENTER OF REAR COMPARTMENT FLOOR BOARD) GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT MID-RANGE SPEAKER LEFT FRONT SUBWOOFER LEFT FRONT TWEETER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER MUTE LR AF- LF AF- LR MR+ LR MR- LF SPKR+ LF SPKR- NCA WIRE REAR FUSE HOLDER RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RF AF+ ANT RF SPKR+ RF SPKR- RR MR+ RF AF- K-BUS RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT SUBWOOFER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE RIGHT REAR TWEETER RR MR- RR- RR+ R SUB- R SUB+ GROUND WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE
