Car Wiring Diagrams for Rear heated seats circuit for BMW X3 E83 facelift (2006-2010)

BLK WIRE BLU WIRE BRN WIRE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START LEFT REAR SEAT BACKREST HEATING LEFT REAR SEAT CUSHION HEATING LEFT REAR SEAT HEATING SWITCH POWER DISTRIBUTION (RIGHT SIDE OF DASH) RED WIRE RIGHT REAR SEAT BACKREST HEATING RIGHT REAR SEAT CUSHION HEATING RIGHT REAR SEAT HEATING SWITCH TERMINAL 15 LOAD SHEDDING RELAY WHT WIRE YEL WIRE
