BMW X3 E83 facelift (2006-2010) w/o basic mirror w/ basic mirror Wiring diagram
This page shows the only wiring diagram for the component.w/o basic mirror w/ basic mirror, which is found in the car BMW X3 E83 facelift (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o basic mirror w/ basic mirror (1 of 1)
BLK/GRN WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
DRIVER'S DOOR MODULE
DRIVER'S WINDOW MOTOR (IN DRIVER'S DOOR)
FUSE
GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH)
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT REAR DOOR POWER WINDOW (IN LEFT REAR DOOR)
LEFT REAR DOOR POWER WINDOW SWITCH
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S WINDOW MOTOR (IN FRONT PASSENGER'S DOOR)
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RED WIRE
RED/GRN WIRE
RIGHT REAR DOOR POWER WINDOW (IN RIGHT REAR DOOR)
RIGHT REAR DOOR POWER WINDOW SWITCH
W/O BASIC MIRROR W/ BASIC MIRROR
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power windows circuit -> W/O BASIC MIRROR W/ BASIC MIRROR
