BMW X3 E83 facelift (2006-2010) multiple restraint system control module Wiring diagram
This page shows the only wiring diagram for the component.multiple restraint system control module, which is found in the car BMW X3 E83 facelift (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multiple restraint system control module (1 of 1)
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CENTER CONSOLE
CENTER CONSOLE SWITCH CENTER
CLUTCH SWITCH
COOLANT LEVEL SWITCH
DIRECTION INDICATOR/ HIGH BEAM HEADLIGHT SWITCH
DRIVER'S SEAT BELT BUCKLE CONTACT
ELECTRONIC INTERIOR REAR-VIEW MIRROR
ELECTRONIC VEHICLE DSC SENSOR IMMOBILIZER
FRONT CIGARETTE LIGHTER LIGHTING
GENERAL MODULE CONTROL MODULE
GRN WIRE
HAZARD WARNING/ CENTRAL LOCKING SWITCH
HOOD CONTACT SWITCH
HORN SWITCH
LEFT FOG LIGHT
LEFT HEADLIGHT
LEFT REAR GEAR SEAT INDICATOR HEATING LIGHTING SWITCH
LIGHT MODULE
MULTI-FUNCTION STEERING WHEEL
MULTIPLE RESTRAINT SYSTEM CONTROL MODULE
MULTIPLE RESTRAINT SYSTEM CONTROL MODULE SHIELD
NCA WIRE
OBD II SOCKET
PASSENGER'S SEAT BELT BUCKLE CONTACT
RADIATOR SHUTTER DRIVE UNIT
RAIN/ HEADLIGHT LEFT SENSOR HEADLIGHT
RIGHT HEADLIGHT
RIGHT REAR SEAT HEATING SWITCH
SEAT OCCUPANCY RECOGNITION
STEERING ANGLE SENSOR
STEPTRONIC SWITCH
TRANSFER BOX CONTROL MODULE
VOLUTE SPRING
WASH WATER LEVEL SWITCH
WIPER SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> MULTIPLE RESTRAINT SYSTEM CONTROL MODULE
