BMW X3 E83 facelift (2006-2010) disa controller 1 Wiring diagrams
This page contains all the electrical diagrams for the component. disa controller 1, in which he is found in the car BMW X3 E83 facelift (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
disa controller 1 wiring diagram (1 of 2)
AUXILIARY BRAKE ANTENNA LIGHT DIVERSITY
BRN WIRE
CRANKSHAFT BREATHER HEATING 1
DISA CONTROLLER 1
DISA CONTROLLER 2
DME CONTROL MODULE
IGNITION COIL CYLINDER 3
IGNITION COIL CYLINDER 4
IGNITION IGNITION COIL COIL CYLINDER 1 CYLINDER 2
IGNITION IGNITION COIL COIL CYLINDER 5 CYLINDER 6
INTEGRATED SUPPLY MODULE (IVM)
LEFT INNER TAILLIGHT
LEFT TAILLIGHT
LUGGAGE COMPARTMENT CHARGING SOCKET
NCA WIRE
NOISE SUPPRESSOR FILTER
OIL CONDITION SENSOR
REAR INTERMITTENT WIPE/WASH CONTROL MODULE
REAR SEAT ENTERTAINMENT PREPARATION
REAR WINDOW DEFROSTER
RIGHT INNER TAILLIGHT
RIGHT TAILLIGHT
TRAILER MODULE
TRAILER SOCKET
TRANSMISSION CONTROL
TRUNK LID CENTRAL LOCKING DRIVE
TRUNK LID PUSH- BUTTON/ LICENSE PLATE LIGHTS
WAVE TRAP 2
Go to component -> Ground distribution circuit (4 of 4) -> DISA CONTROLLER 1
disa controller 1 wiring diagram (2 of 2)
ACCELERATOR PEDAL MODULE
AIR MASS FLOW SENSOR
ANTI-THEFT SYSTEM
BLK/BLU WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/GRY WIRE
DISA CONTROLLER 1
DME RELAY
E-BOX FAN
EXHAUST FLAP CRANKSHAFT (LEFT SIDE SENSOR OF REAR COMPT)
FUEL TANK VENT VALVE DISA CONTROLLER 2
FUSE
FUSE FUSE
GRY/VIO WIRE
INTEGRATED SUPPLY MODULE (IVM)
NCA WIRE
OIL CONDITION SENSOR
ORG/ WIRE
RED WIRE
RED/WHT WIRE
STARTING/ CHARGING SYSTEM
TO VVT RELAY (DIAGRAM 3 OF 4)
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.0l (2 of 4) -> DISA CONTROLLER 1
