Car Wiring Diagrams for Supplemental restraints circuit for BMW X3 E83 (2003-2006)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE DRIVER SIDE AIRBAG INFLATOR ASSEMBLY DRIVER'S SEAT BELT TENSIONER GENERATOR GRN WIRE GRY/BLK WIRE GRY/BRN WIRE LEFT FRONT DOOR SATELLITE LEFT HEAD AIRBAG INFLATOR ASSEMBLY LEFT REAR SIDE AIRBAG INFLATOR ASSEMBLY MULTIPLE RESTRAINTS SYSTEM CONTROL MODULE (CENTER CONSOLE) NCA WIRE PASSENGER SIDE AIRBAG INFLATOR ASSEMBLY PASSENGER'S SEAT BELT TENSIONER GENERATOR RED WIRE RIGHT HEAD AIRBAG INFLATOR ASSEMBLY RIGHT REAR SIDE AIRBAG INFLATOR ASSEMBLY WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

2005 ONLY BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE CENTER CONSOLE COMPUTER DATA LINES SYSTEM DRIVER'S AIRBAG INFLATOR ASSEMBLY GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/VIO WIRE INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE PASSENGER AIRBAG DEACTIVATION SWITCH PASSENGER'S AIRBAG INFLATOR ASSEMBLY RED WIRE RIGHT FRONT AIRBAG SENSOR SAFETY BATTERY TERMINAL GENERATOR SEAT OCCUPANCY RECOGNITION VIO WIRE VIO/BLU WIRE VOLUTE SPRING WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

AIRBAG INDICATOR LIGHT BLK WIRE BLU WIRE BLU/VIO/YEL WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE CENTER CONSOLE DRIVER'S SEAT BELT BUCKLE CONTACT FUSE GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE HOT IN ACCY, RUN, START LEFT B-PILLAR AIRBAG SENSOR LEFT FRONT AIRBAG SENSOR MULTIPLE RESTRAINTS SYSTEM CONTROL MODULE (CENTER CONSOLE) NCA WIRE PASSENGER'S SEAT BELT BUCKLE CONTACT POWER DISTRIBUTION (RIGHT SIDE OF DASH) RIGHT B-PILLAR AIRBAG SENSOR RIGHT FRONT DOOR SATELLITE VIO WIRE VIO/BLU WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
