Electrochromic mirror circuit for BMW X3 E83 (2003-2006)
Electrochromic mirror circuit
1 2 3 4 5 6 7 REVERSE SIG
ANTI-THEFT LED
BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER'S SIDE OUTSIDE MIRROR
ELECTRO- CHROMIC ACTIVATION
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS)
FUSE
GENERAL MODULE CONTROL UNIT (RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY/BLK/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
NCA WIRE
PASSENGER'S SIDE OUTSIDE MIRROR
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
TERM 15 ELECHRMC ACT ELECHRMC ACT ELECHRMC ACT ELECHRMC ACT ELECHRMC ACT
W/ OUTSIDE MIRROR CAMERA W/O OUTSIDE MIRROR CAMERA
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
