Navigation circuit, with multi-information radio for BMW X3 E83 (2003-2006)
Navigation circuit, with multi-information radio
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 REVERSE SIG
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 TERMINAL 30
ANTI-LOCK BRAKES SYSTEM
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GROUND
HOT AT ALL TIMES
HOT IN RUN, ACCY OR
K-BUS SIG
NAVIGATION SYSTEM
NCA WIRE
NEGATIVE ACTIVATION RADIO
POSITIVE ACTIVATION RADIO
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RADIO
RED/YEL WIRE
ROOF ANTENNA
SIG NAV BUS
SPEED SIG
TERMINAL R
VIO/WHT WIRE
WHT/GRY WIRE
WHT/RED/YEL WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
