BMW X3 E83 (2003-2006) steering wheel heating Wiring diagram
This page shows the only wiring diagram for the component.steering wheel heating, which is found in the car BMW X3 E83 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel heating (1 of 1)
AMPLIFIER
ANTI-THEFT ALARM SYSTEM HORN
AUXILIARY BRAKE LIGHT ANTENNA DIVERSITY
BRN WIRE
CD CHANGER
CENTRAL INFORMATION DISPLAY
EJECT BOX
EMERGENCY CALL BUTTON
FRONT CIGAR LIGHTER
FRONT CIGARETTE LIGHTER LIGHTING
FRONT INTERIOR/ READING LAMP
GENERAL MODULE CONTROL MODULE PASSENGER'S SEAT ADJUSTMENT SWITCH
GLOVE COMPT LIGHT SERVO- TRONIC
HEATING/ AIR CONDITIONING SYSTEM BLOWER OUTPUT STAGE
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR MOVEMENT DETECTOR
LEFT FRONT MAKE UP MIRROR SWITCH
LEFT HEATED WASHER NOZZLE RIGHT HEATED WASHER NOZZLE
NAVIGATION SYSTEM
NCA WIRE
PANORAMA GLASS ROOF SWITCH
PASSENGER'S DOOR POWER WINDOW SWITCH
PASSENGER'S DOOR SYSTEM LOCK PASSENGER'S WINDOW MOTOR
PASSENGER'S LUMBAR SUPPORT VALVE BLOCK PASSENGER'S LUMBAR SUPPORT SWITCH
PASSENGER'S SEAT BACKREST HEATING PASSENGER'S SEAT CUSHION HEATING
PASSENGER'S SIDE OUTSIDE MIRROR
RADIO
REAR CIGARETTE LIGHTER FLASHLIGHT CHARGING SOCKET
RIGHT FRONT DIRECTION INDICATOR LIGHT REPEATER
RIGHT FRONT MAKE-UP MIRROR SWITCH LEFT REAR INTERIOR LIGHT
RIGHT REAR DOOR POWER WINDOW SWITCH
RIGHT REAR DOOR SYSTEM LOCK RIGHT REAR WINDOW MOTOR
RIGHT REAR INTERIOR LIGHT
SATELLITE RECEIVER
STEERING WHEEL HEATING
STEERING WHEEL HEATING CONTROL MODULE
TELEPHONE TRANSCEIVER
VIDEO MODULE
VOICE CONTROL SYSTEM
VOLUTE SPRING
W/ STEREO
W/O STEREO
Go to component -> Ground distribution circuit (3 of 4) -> STEERING WHEEL HEATING
