BMW X3 E83 (2003-2006) left front subwoofer speaker Wiring diagrams
This page contains all the electrical diagrams for the component. left front subwoofer speaker, in which he is found in the car BMW X3 E83 (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front subwoofer speaker (1 of 2)
1 2 3 4 5 6 7 8 RF + RF + LF + LF + RF - RF - LF - LF -
1 2 PINS: 3-7 (NOT USED) 8 9 PINS: 10-12 (NOT USED)
9 10 11 12 13 14 15 16 K-BUS MUTE TELE ON GROUND ANTENNA LIGHT TERM 30 TERM R
ANTENNA
ANTENNA DIVERSITY
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
CD AF+ R CD AF+ L
CD AF-
CD CHANGER
COMPUTER DATA LINES SYSTEM
FUSE
GENERAL MODULE CONTROL UNIT
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN, ACC OR START
LEFT ANTENNA
LEFT FRONT LOUD- SPEAKER
LEFT FRONT SUBWOOFER SPEAKER
NAVI + TELE AF+
NAVI - TERM 50
NAVIGATION SYSTEM
NCA WIRE
NOISE SUPPRESSOR FILTER
PARTIAL
POWER DISTRIBUTION (RIGHT SIDE OF DASH)
RADIO
RADIO NAVI
REAR-WINDOW AERIAL
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT ANTENNA
RIGHT FRONT LOUD- SPEAKER
RIGHT FRONT SUBWOOFER SPEAKER
TELEPHONE TRANSCEIVER
VIDEO MODULE
VIO/WHT WIRE
VOICE CONTROL SYSTEM
W/ VIDEO MODULE
W/ VOICE RECOGNITION SYSTEM
W/O VIDEO MODULE
W/O VOICE RECOGNITION SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Base radio circuit -> LEFT FRONT SUBWOOFER SPEAKER
Wiring diagram left front subwoofer speaker (2 of 2)
AMPLIFIER
BLK WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT SUBWOOFER SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT REAR MID-RANGE SPEAKER
LFW- LFW+ 30
LR AF+ LF AF+
MUTE LR AF- LF AF- LR MR+ LR MR- LFT+ LFT-
NCA WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT SUBWOOFER SPEAKER
RIGHT FRONT TWEETER SPEAKER
RIGHT REAR MID-RANGE SPEAKER
RR AF+ RF AF+ ANT RFT+ RFT- RR MR+
RR AF- RF AF- K-BUS
RR MR- RFW- RFW+
WHT WIRE
WHT/RED/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Premium radio circuit, hifi radio (2 of 2) -> LEFT FRONT SUBWOOFER SPEAKER
