Blind spot monitoring circuit, w/ front & rear radar sensors for BMW X3 M F97 facelift (2021-2024)
Blind spot monitoring circuit, w/ front & rear radar sensors (1 of 2)
ALL ROUND VISION CAMERA
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE 204
FUSE 208
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HEATING ACC SENSOR (ON ACTIVE CRUISE CONTROL)
HOT W/
LONG-DISTANCE RANGE FRONT RADAR SENSOR
OPTIONAL EQUIPMENT SYSTEM (LEFT KICK PANEL)
ORG/GRN WIRE
ORG/YEL WIRE
PARKING MANEUVERING ASSISTANT (RIGHT REAR QUARTERPANEL)
PNK/BLU WIRE
REAR POWER DISTRIBUTION BOX
RED/GRN WIRE
RELAY ENERGIZED
W/O SURROUND VIEW CAMERA
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Blind spot monitoring circuit, w/ front & rear radar sensors (2 of 2)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 206
FUSE 208
GRN WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/VIO WIRE
HOT W/
LEFT FRONT SIDE NEAR RANGE RADAR SENSOR
LEFT REAR NEAR RANGE RADAR SENSOR
REAR POWER DISTRIBUTION BOX
RED WIRE
RELAY ENERGIZED
RIGHT FRONT SIDE NEAR RANGE RADAR SENSOR
RIGHT REAR NEAR RANGE RADAR SENSOR
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
