Air suspension circuit for BMW X3 M F97 facelift (2021-2024)
Air suspension circuit
ACTIVE CRUISE CONTROL
BLU WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
ETHERNET SWITCH
FUSE 204
FUSE 39
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/
LEFT FRONT LANE CHANGE WARNING SLAVE
LEFT FRONT LEVEL SENSOR
LEFT REAR LEVEL SENSOR
OPTIONAL EQUIPMENT SYSTEM
PNK/BLU WIRE
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT LANE CHANGE WARNING SLAVE
RIGHT FRONT POWER DISTRIBUTION BOX
W/ ETHERNET SWITCH
W/O ETHERNET SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRY WIRE
