Access/start circuit for BMW X3 M F97 facelift (2021-2024)
Access/start circuit
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
CENTER REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DRIVER OUTSIDE DOOR HANDLE ELECTRONICS
FRONT CENTER CONSOLE INTERIOR ANTENNA
FUSE 13
FUSE 504
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES FUSE BOX
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT EXTERIOR ANTENNA
LUGGAGE COMPARTMENT ANTENNA
PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS
REAR CENTER CONSOLE INTERIOR ANTENNA
REAR DRIVER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REAR PASSENGER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
RED WIRE
RIGHT EXTERIOR ANTENNA
RING ANTENNA
START-STOP BUTTON
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
