BMW X3 M F97 facelift (2021-2024) automatic hold function led Wiring diagrams
This page contains all the electrical diagrams for the component. automatic hold function led, in which he is found in the car BMW X3 M F97 facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
automatic hold function led wiring diagram (1 of 2)
AUTOMATIC HOLD BUTTON
AUTOMATIC HOLD FUNCTION LED
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DYNAMIC STABILITY CONTROL (DSC)
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 28
FUSE 29
FUSE 32
FUSE 404
GRN/BLU WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT BRAKE PAD WEAR SENSOR
NCA WIRE
PARKING BRAKE BUTTON
PARKING BRAKE INDICATOR LIGHT
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT WHEEL RPM SENSOR
RIGHT PARKING BRAKE DRIVE
RIGHT REAR BRAKE PAD WEAR SENSOR
RIGHT REAR WHEEL RPM SENSOR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> AUTOMATIC HOLD FUNCTION LED
automatic hold function led wiring diagram (2 of 2)
AUTOMATIC HOLD BUTTON
AUTOMATIC HOLD FUNCTION LED
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DYNAMIC STABILITY CONTROL (DSC)
FUSE 28
FUSE 32
GRN/BLU WIRE
HOT AT ALL TIMES
LEFT PARKING BRAKE DRIVE
NCA WIRE
PARKING BRAKE BUTTON
PARKING BRAKE INDICATOR LIGHT
PNK/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT PARKING BRAKE DRIVE
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> AUTOMATIC HOLD FUNCTION LED
