Receiver audio module circuit, high level for BMW X3 M F97 (2019-2021)

BLK WIRE BLU WIRE BLUETOOTH ANTENNA BODY DOMAIN CONTROLLER BRN WIRE BRN/WHT WIRE CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM CONTROLLER EMERGENCY LOUD SPEAKER FUSE 13 FUSE 212 FUSE 215 FUSE 217 FUSE 220 FUSE 61 GPS ANTENNA GRN WIRE GRN/BLU WIRE GRY WIRE HEAD UNIT HOT W/ BI-STABLE RELAY ENERGIZED HOT W/ TERMINAL INSTRUMENT PANEL NCA WIRE ORG/ WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT FRONT POWER DISTRIBUTION BOX ROOF ANTENNA SDARS ANTENNA TELEMATIC COMMUNICATION BOX (IF EQUIPPED) (REAR CENTER OF ROOF) USB CHARGING SOCKET 3 USB PORT USB CONNECTION W/O TELEMATICS WHT WIRE WHT/BLU WIRE WLAN ANTENNA YEL WIRE

ACOUSTIC PEDESTRIAN PROTECTION SPEAKER ACOUSTIC PEDESTRIAN PROTECTION SPEAKER 2 BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BOOSTER BRN WIRE BRN/WHT WIRE CARD READER COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE LEFT FRONT BASS SPEAKER MICROPHONE MICROPHONE 2 + NCA WIRE REAR SPOILER ANTENNA REAR WINDOW ANTENNA RECEIVER AUDIO MODULE RED WIRE RED/BLU WIRE RED/GRY WIRE RIGHT FRONT BASS SPEAKER W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BLU WIRE YEL WIRE

ANTENNA SIGNAL AMPLIFIER 3 BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CENTER FRONT MID-RANGE SPEAKER CENTER FRONT TWEETER GRN/BLU WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR MID- RANGE SPEAKER 2 LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER LEFT REAR TWEETER 2 LEFT SIDE WINDOW ANTENNA NCA WIRE RECEIVER AUDIO MODULE RED WIRE RED/BLU WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID- RANGE SPEAKER 2 RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER RIGHT REAR TWEETER 2 RIGHT SIDE WINDOW ANTENNA VIO/BRN WIRE VIO/RED WIRE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE
