Power windows circuit for BMW X3 M F97 (2019-2021)
Power windows circuit
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S SIDE REAR POWER WINDOW SWITCH
FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
FRONT PASSENGER'S DOOR POWER WINDOW SWITCH
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 29
FUSE 67
GRY/BLK WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/
LIN BUS SIG
PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
PASSENGER'S SIDE REAR POWER WINDOW SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
TERMINAL 30 SPLY
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
