Front heated seats circuit, w/o memory for BMW X3 M F97 (2019-2021)
Front heated seats circuit, w/o memory
AIR CONDITIONING (BEHIND GLOVE BOX)
BLK WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER THIGH SUPPORT HEATING
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT SURFACE HEATING
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS
FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATER/SENSOR
FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT SURFACE HEATING/SENSOR
FRONT PASSENGER THIGH SUPPORT HEATING
FRONT PASSENGER'S SEAT BACKREST HEATING
FUSE 48
FUSE 52
GRN WIRE
GRN/VIO WIRE
GRY WIRE
NCA WIRE
REAR DRIVER'S SIDE SEAT HEATING MODULE
REAR PASSENGER'S SIDE SEAT HEATING MODULE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
VIO WIRE
W/ EXTENDABLE THIGH SUPPORT
W/O EXTENDABLE THIGH SUPPORT
YEL WIRE
