Horn circuit for BMW X3 M F97 (2019-2021)
Horn circuit
BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/RED WIRE
ELECTRONICS JUNCTION BOX
FANFARE HORN RELAY
FUSE 10
FUSE 7
GRY/BLK WIRE
HIGH RANGE HORN
HORN BUTTON
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT MULTI-FUNCTION STEERING WHEEL SWITCH CLUSTER
LEFT SHIFT PADDLE
LOW RANGE HORN
NCA WIRE
RED/BLU WIRE
RED/GRY WIRE
RIGHT SHIFT PADDLE
STEERING COLUMN SWITCH CLUSTER
W/ M SPORTS STEERING WHEEL
WHT WIRE
