Trailer tow circuit for BMW X3 M F97 (2019-2021)
Trailer tow circuit (1 of 2)
Trailer tow circuit (2 of 2)
BLK WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER EXTERIOR MIRROR
FUSE 240
FUSE 289
FUSE 295
FUSE 50
FUSE 504
FUSE BOX
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
NOISE SUPPRESSOR FILTER
PREPARATION TRAILER MODULE PLUG CONNECTION
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/VIO WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
TRAILER BRAKE SYSTEM PLUG CONNECTION
W/ PREPARATION TRAILER MODULE
W/ TRAILER MODULE
W/ TRAILER SOCKET
W/O TRAILER SOCKET
YEL/BRN WIRE
YEL/RED WIRE
