Automatic a/c circuit for BMW X2 F39 (2017-2023)

AIR CONDITIONING COMPRESSOR AIR DISTRIBUTION MICROSWITCH AUC SENSOR AUDIO CONTROL PANEL BASIC BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CONTROL VALVE FRONT POWER DISTRIBUTION BOX FUSE 11 FUSE 53 GRN WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HEATING, AIR CONDITIONING SYSTEM CONTROL PANEL HEATING/AIR CONDITIONING SYSTEM HOT W/ BI-STABLE RELAY ENERGIZED HOT W/ TERMINAL MAGNETIC COUPLING OUTSIDE TEMPERATURE SENSOR RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE REFRIGERANT PRESSURE SENSOR VIO WIRE VIO/GRN WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE

AIR DISTRIBUTION FLAP MOTOR BASIC BLOWER MOTOR (TOP OF HVAC UNIT) BLOWER OUTPUT STAGE BLU WIRE BRN WIRE BRN/WHT WIRE DEFROSTER FLAP MOTOR EVAPORATOR TEMPERATURE SENSOR FOOTWELL FLAP MOTOR FOOTWELL TEMPERATURE SENSOR FRESH AIR/RECIRCULATED AIR FLAP MOTOR FRONT ELECTRIC AUXILIARY HEATER FRONT POWER DISTRIBUTION BOX FUSE 34 FUSE 405 FUSE 72 FUSE BOX GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT MIXED AIR FLAP MOTOR MIXED AIR FLAP MOTOR NCA WIRE RED WIRE RED/VIO WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT MIXED AIR FLAP MOTOR VENTILATION TEMPERATURE SENSOR YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/VIO WIRE

BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLANT TEMPERATURE SENSOR CRANKCASE COOLANT SHUTOFF VALVE CRANKCASE TEMPERATURE SENSOR DIGITAL MOTOR ELECTRONICS ELECTRIC FAN ELECTRIC FAN CUT OUT RELAY FRONT POWER DISTRIBUTION BOX FUSE 1 FUSE 401 FUSE 50 FUSE 74 FUSE 83 FUSE BOX HEAT MANAGEMENT MODULE (LEFT SIDE OF ENGINE) HOT AT ALL TIMES HOT W/ HOT W/ TERMINAL INTEGRATED SUPPLY MODULE RADIATOR BLIND DRIVE RADIATOR OUTLET TEMPERATURE SENSOR RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT SIDE OF RADIATOR) TURBOCHARGER COOLANT PUMP VIO WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE
