BMW X2 F39 (2017-2023) usb/ethernet selector switch head unit basic w/ Wiring diagrams
This page contains all the electrical diagrams for the component. usb/ethernet selector switch head unit basic w/, in which he is found in the car BMW X2 F39 (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram usb/ethernet selector switch head unit basic w/ (1 of 2)
BASE PLATE (IN CENTER CONSOLE)
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CAR SHARING MODULE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 101
FUSE 51
FUSE 79
GRN WIRE
HEAD UNIT (CENTER OF DASH)
HOT AT ALL TIMES
HOT W/ TERMINAL
ID READER
NAVIGATION
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
USB/ETHERNET SELECTOR SWITCH HEAD UNIT BASIC W/
VIO WIRE
W/ ANTENNA AMPLIFIER
W/ WIRELESS CHARGING STORAGE
W/O ANTENNA AMPLIFIER
W/O WIRELESS CHARGING STORAGE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Hifi radio circuit, w/ active sound design (3 of 6) -> USB/ETHERNET SELECTOR SWITCH HEAD UNIT BASIC W/
Wiring diagram usb/ethernet selector switch head unit basic w/ (2 of 2)
BASE PLATE (IN CENTER CONSOLE)
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
CAR SHARING MODULE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 101
FUSE 51
FUSE 79
GRN WIRE
HEAD UNIT (CENTER OF DASH)
HOT AT ALL TIMES
HOT W/ TERMINAL
ID READER
NAVIGATION
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
USB/ETHERNET SELECTOR SWITCH HEAD UNIT BASIC W/
VIO WIRE
W/ ANTENNA AMPLIFIER
W/ WIRELESS CHARGING STORAGE
W/O ANTENNA AMPLIFIER
W/O WIRELESS CHARGING STORAGE
WHT/GRN WIRE
WHT/RED WIRE
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
WIRELESS CHARGING STORAGE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, w/ hifi radio & active sound design (3 of 6) -> USB/ETHERNET SELECTOR SWITCH HEAD UNIT BASIC W/
