BMW X2 F39 (2017-2023) usb charging port 4 Wiring diagram
This page shows the only wiring diagram for the component.usb charging port 4, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram usb charging port 4 (1 of 1)
12 POWER SOCKET 1
BASE PLATE FAN
BLOWER OUTPUT STAGE
BOOT LID/ TAILGATE LOCK
BRN WIRE
CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS
DIAGNOSTIC SOCKET
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER SIDE REAR INTERIOR TRIM LIGHTING
DRIVER VEHICLE EXTERIOR MIRROR
DRIVER'S DOOR ENTRY LIGHTING
DRIVER'S DOOR GROUND LIGHTS
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S DOOR TRIM PANEL LIGHTING
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT MODULE
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE INTERIOR TRIM LIGHTING
DRIVER'S SIDE REAR DOOR SILL COURTESY LIGHT
DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE REAR FOOTWELL LIGHT
DRIVER'S SIDE REAR GROUND LIGHTS
ELECTRICAL EXHAUST FLAP
ELECTRICAL FUEL PUMP CONTROL ELECTRONIC
LEFT INNER TAILGATE
LEFT INNER TAILLIGHT
LEFT OUTER TAILLIGHT
LONGITUDINAL TORQUE DISTRIBUTION
NATURAL VACUUM LEAK DETECTION
NCA WIRE
OPTIONAL EXTRA SYSTEM
OUTER TAILGATE BUTTON
REAR VIEW CAMERA
REAR WINDOW DEFOGGER
REAR WIPER
REFUELING BUTTON
RIGHT INNER TAILLIGHT
RIGHT OUTER TAILLIGHT
TAILGATE FUNCTION MODULE
TRAILER MODULE
TRAILER SOCKET
USB CHARGING PORT 4
VEHICLE INTERIOR TAILGATE BUTTON
W/ TRAILER MODULE
W/ WIRELESS CHARGING STORAGE
W/O WIRELESS CHARGING STORAGE
WHT WIRE
Go to component -> Ground distribution circuit (2 of 4) -> USB CHARGING PORT 4
