BMW X2 F39 (2017-2023) touch detection electronics Wiring diagram
This page shows the only wiring diagram for the component.touch detection electronics, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram touch detection electronics (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BODY DOMAIN CONTROLLER
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS (LEFT REAR OF ENGINE COMPT)
DYNAMIC STABILITY CONTROL (DSC)
ELECTROMECHANICAL POWER STEERING
ELECTRONIC STEERING WHEEL MODULE
ELECTRONIC TRANSMISSION CONTROL
FRONT POWER DISTRIBUTION BOX
FUSE 32
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
INTELLIGENT BATTERY SENSOR
NCA WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/RED WIRE
RED WIRE
RED/BLU WIRE
RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK
STEERING COLUMN SWITCH CLUSTER
TOP OF TRANSMISSION)
TOUCH DETECTION ELECTRONICS
TURBOCHARGER COOLANT PUMP
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> High/low bus circuit (1 of 4) -> TOUCH DETECTION ELECTRONICS
