BMW X2 F39 (2017-2023) supply term 30 Wiring diagram
This page shows the only wiring diagram for the component.supply term 30, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram supply term 30 (1 of 1)
BLK/GRN WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
DRIVER RETRACTOR TENSIONER
DRIVER SIDE AIR BAG GAS GENERATOR
FLEX RAY BUS SIG
FRONT PASSENGER SEAT OCCUPANCY DETECTION
FRONT POWER DISTRIBUTION BOX
FUSE 32
GRN WIRE
GROUND
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT AIR BAG SENSOR
LEFT HEAD AIR BAG GAS GENERATOR
LEFT PEDESTRIAN PROTECTION SENSOR
PNK/BLK WIRE
PNK/BLU WIRE
RED/BLU WIRE
RIGHT FRONT AIR BAG SENSOR
RIGHT REAR PEDESTRIAN PROTECTION ACTUATOR
SUPPLY TERM 30
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> SUPPLY TERM 30
