BMW X2 F39 (2017-2023) right rear valve coil Wiring diagram
This page shows the only wiring diagram for the component.right rear valve coil, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear valve coil (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 35
FUSE 60
FUSE 92
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/
LEFT FRONT VALVE COIL
LEFT REAR VALVE COIL
OPTIONAL EXTRA SYSTEM
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT RIDE HEIGHT SENSOR
RIGHT FRONT VALVE COIL
RIGHT REAR RIDE HEIGHT SENSOR
RIGHT REAR VALVE COIL
VIO WIRE
VIO/BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electronic suspension circuit -> RIGHT REAR VALVE COIL
