BMW X2 F39 (2017-2023) right rear electronic wheel system Wiring diagram
This page shows the only wiring diagram for the component.right rear electronic wheel system, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear electronic wheel system (1 of 1)
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 42
HOT AT ALL TIMES
LEFT FRONT ELECTRONIC WHEEL SYSTEM
LEFT REAR ELECTRONIC WHEEL SYSTEM
RED WIRE
RED/GRN WIRE
REMOTE CONTROL RECEIVER (RIGHT SIDE OF LUGGAGE COMPT)
RIGHT FRONT ELECTRONIC WHEEL SYSTEM
RIGHT REAR ELECTRONIC WHEEL SYSTEM
Go to component -> Warning systems circuit -> RIGHT REAR ELECTRONIC WHEEL SYSTEM
