BMW X2 F39 (2017-2023) passenger's side seat adjustment switch block Wiring diagrams
This page contains all the electrical diagrams for the component. passenger's side seat adjustment switch block, in which he is found in the car BMW X2 F39 (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger's side seat adjustment switch block (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
RED WIRE
RELAY ENERGIZED
SPORT SEATS CIRCUIT
Go to component -> Lumbar circuit, w/ electric seat adjustment -> PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
Wiring diagram passenger's side seat adjustment switch block (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
FRONT PASSENGER SEAT ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT BACKREST ANGLE ADJUSTMENT DRIVE
FRONT PASSENGER SEAT FORWARD/ BACK ADJUSTMENT DRIVE
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT DRIVE
FRONT POWER DISTRIBUTION BOX
FUSE 95
GRN WIRE
HOT W/
LUMBAR CIRCUIT
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
RED WIRE
RELAY ENERGIZED
SPORT SEAT CIRCUIT
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
