BMW X2 F39 (2017-2023) passenger's side rear courtesy lighting Wiring diagram
This page shows the only wiring diagram for the component.passenger's side rear courtesy lighting, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side rear courtesy lighting (1 of 1)
BODY DOMAIN CONTROLLER
BRN WIRE
FRONT PASSENGER DOOR ENTRY LIGHTING
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FRONT PASSENGER'S DOOR GROUND LIGHT
FRONT PASSENGER'S DOOR TRIM PANEL LIGHTING
FRONT POWER DISTRIBUTION BOX
PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
PASSENGER'S SIDE INTERIOR TRIM LIGHTING
PASSENGER'S SIDE REAR COURTESY LIGHTING
PASSENGER'S SIDE REAR DOOR TRIM PANEL LIGHTING
PASSENGER'S SIDE REAR FOOTWELL LIGHT
PASSENGER'S SIDE REAR INTERIOR TRIM LIGHTING
PASSENGER'S SIDE REAR SILL COURTESY LIGHTING
ROOF FUNCTION CENTER
Go to component -> Ground distribution circuit (4 of 4) -> PASSENGER'S SIDE REAR COURTESY LIGHTING
