BMW X2 F39 (2017-2023) passenger's side rear courtesy light Wiring diagram
This page shows the only wiring diagram for the component.passenger's side rear courtesy light, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side rear courtesy light (1 of 1)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR ENTRY LIGHTING
DRIVER'S DOOR GROUND LIGHTS
DRIVER'S SIDE REAR DOOR SILL COURTESY LIGHT
DRIVER'S SIDE REAR FOOTWELL LIGHT
DRIVER'S SIDE REAR GROUND LIGHTS
FRONT PASSENGER DOOR ENTRY LIGHTING
FRONT PASSENGER'S DOOR GROUND LIGHT
FUSE 404
FUSE BOX
GRY WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT FOOTWELL LIGHT
ORG/ WIRE
PASSENGER'S SIDE REAR COURTESY LIGHT
PASSENGER'S SIDE REAR FOOTWELL LIGHT
PASSENGER'S SIDE REAR SILL COURTESY LIGHT
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RIGHT FRONT FOOTWELL LIGHT
WHT/GRN WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (4 of 4) -> PASSENGER'S SIDE REAR COURTESY LIGHT
