BMW X2 F39 (2017-2023) parking lights/ daytime running light 2 led module Wiring diagram
This page shows the only wiring diagram for the component.parking lights/ daytime running light 2 led module, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking lights/ daytime running light 2 led module (1 of 1)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
FAN
FRONT POWER DISTRIBUTION BOX
FUSE 32
FUSE 47
FUSE 62
FUSE 9
GRN WIRE
HEADLIGHT BEAM THROW ADJUSTMENT DRIVE
HIGH BEAM
HIGH BEAM ASSISTANT SENSOR, CONTROL
HOT AT ALL TIMES
HOT W/
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT FRONTAL LIGHT ELECTRONICS
LEFT HEADLIGHT
LIGHT OPERATING UNIT
LOW BEAM
PARKING LAMPS/DAYTIME RUNNING LIGHTS LED MODULE
PARKING LIGHTS/ DAYTIME RUNNING LIGHT 2 LED MODULE
RAIN/LIGHT/SOLAR CONDENSATION SENSOR
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
SIDE LIGHTS/ DAYTIME DRIVING LIGHT
STEERING COLUMN SWITCH CLUSTER
VIO/YEL WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit, w/ led headlamps (1 of 2) -> PARKING LIGHTS/ DAYTIME RUNNING LIGHT 2 LED MODULE
