BMW X2 F39 (2017-2023) light source 2 light source 3 Wiring diagram
This page shows the only wiring diagram for the component.light source 2 light source 3, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light source 2 light source 3 (1 of 1)
BLU WIRE
BRN WIRE
DRIVER'S DOOR DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE INTERIOR TRIM LIGHTING
DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE REAR INTERIOR TRIM LIGHTING
FRONT PASSENGER DOOR TRIM PANEL LIGHTING
GRN WIRE
GRY WIRE
GRY/RED WIRE
LIGHT SOURCE 2
LIGHT SOURCE 2 LIGHT SOURCE 3
LIGHT SOURCE 3 LIGHT SOURCE 5
LIGHT SOURCE 4
LIGHT SOURCE 4 LIGHT SOURCE 6
LIGHT SOURCE 4 LIGHT SOURCE 7
LIGHT SOURCE 5 LIGHT SOURCE 9
LIGHT SOURCE 8
ORG/ WIRE
ORG/YEL WIRE
PASSENGER'S SIDE INTERIOR TRIM LIGHTING
PASSENGER'S SIDE REAR DOOR TRIM PANEL LIGHTING
PASSENGER'S SIDE REAR INTERIOR TRIM LIGHTING
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
W/ INTERIOR TRIM LIGHTING
W/O INTERIOR TRIM LIGHTING
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 4) -> LIGHT SOURCE 2 LIGHT SOURCE 3
