BMW X2 F39 (2017-2023) lhz led Wiring diagram
This page shows the only wiring diagram for the component.lhz led, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lhz led (1 of 1)
BLK WIRE
BODY DOMAIN CONTROLLER
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONICS TOUCH DETECTION
ELSV
FANFARE HORN BUTTON
FRONT POWER DISTRIBUTION BOX
FUSE 32
FUSE 58
GRY WIRE
GUARD
HOT AT ALL TIMES
HOT W/ TERMINAL
K-LIN
LEFT MULTI-FUNCTION STEERING COLUMN SWITCH CLUSTER
LEFT SHIFT PADDLE
LHZ LED
LHZ S
LHZ-
NCA WIRE
PWR BFI
RED/BLK WIRE
RED/BLU WIRE
RIGHT SHIFT PADDLE
RIGHT STEERING WHEEL MULTI-FUNCTION SWITCH CLUSTER
SENSE
STEERING COLUMN ADJUSTMENT, HEATED STEERING WHEEL SWITCH
STEERING COLUMN SWITCH CLUSTER
STEERING WHEEL HEATER
STEERING WHEEL MODULE
T LHZ-
TOUCH DETECTION SENSOR
VIBRATION ACTUATOR
Go to component -> Heated steering wheel circuit -> LHZ LED
