BMW X2 F39 (2017-2023) left taillight act Wiring diagram
This page shows the only wiring diagram for the component.left taillight act, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left taillight act (1 of 1)
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BODY CAN BUS SIG
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRK LIGHT ACT
BRK LIGHT SW SIG
BRN WIRE
COMPUTER DATA LINES SYSTEM
FLASHING IND LAMP ACT
FRONT POWER DISTRIBUTION BOX
FUSE 119
FUSE 120
FUSE 63
GRN/BLU WIRE
GRY/BLK WIRE
GRY/RED WIRE
HAZARD WARNING LIGHT SW SIG
HOT W/ BI-STABLE RELAY ENERGIZED
HOT W/ TERMINAL
K-CAN BUS SIGNAL
LEFT TAILLIGHT ACT
LT TURN SIG LIGHT ACT
NOISE SUPPRESSION FILTER
REAR FOG LIGHT ACT
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/YEL WIRE
REVERSING LIGHT ACT
RT TAILLIGHT ACT
RT TURN SIG LIGHT ACT
TERM 31
TRAILER MODULE
TRAILER SOCKET
W/ INTERFERENCE SUPPRESSION FILTER
W/ TRAILER MODULE
W/O TRAILER MODULE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Trailer tow circuit -> LEFT TAILLIGHT ACT
