BMW X2 F39 (2017-2023) left front bass speaker Wiring diagrams

ACTIVE SOUND DESIGN (LEFT SIDE OF LUGGAGE COMPT) BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 68 FUSE 91 GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER NCA WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MID-RANGE SPEAKER ROOF ANTENNA SDARS, TELEPHONE, DABL, GPS AERIALS TOUCH BOX VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM FRONT CENTER MID-RANGE SPEAKER FRONT CENTER TWEETER FRONT POWER DISTRIBUTION BOX FUSE 129 GRN/GRY WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HI-FI AMPLIFIER (LEFT REAR OF LUGGAGE COMPT) HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER NCA WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER VIO WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HI-FI AMPLIFIER (LEFT REAR OF LUGGAGE COMPT) LEFT FRONT BASS SPEAKER NCA WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER ROOF AERIAL TELEPHONE, DABL, SDARS AERIALS VIO WIRE VIO/BRN WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM FRONT CENTER MID-RANGE SPEAKER FRONT CENTER TWEETER FRONT POWER DISTRIBUTION BOX FUSE 129 GRN/GRY WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HI-FI AMPLIFIER (LEFT REAR OF LUGGAGE COMPT) HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER NCA WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER VIO WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN/BLU WIRE BRN/ORG WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HI-FI AMPLIFIER (LEFT REAR OF LUGGAGE COMPT) LEFT FRONT BASS SPEAKER NCA WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER ROOF AERIAL TELEPHONE, DABL, SDARS AERIALS VIO WIRE VIO/BRN WIRE VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

ACTIVE SOUND DESIGN (LEFT SIDE OF LUGGAGE COMPT) BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM CONTROLLER (IDRIVE) FRONT POWER DISTRIBUTION BOX FUSE 61 FUSE 68 FUSE 91 GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT W/ TERMINAL LEFT FRONT BASS SPEAKER LEFT FRONT MID-RANGE SPEAKER NCA WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT BASS SPEAKER RIGHT FRONT MID-RANGE SPEAKER ROOF ANTENNA SDARS, TELEPHONE, DABL, GPS AERIALS TOUCH BOX VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ TELEMATICS W/O TELEMATICS WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE
