BMW X2 F39 (2017-2023) heating/ air conditioning system Wiring diagram
This page shows the only wiring diagram for the component.heating/ air conditioning system, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heating/ air conditioning system (1 of 1)
BASIC VERSION HIGH VERSION
BLK WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER ASSISTANCE SYSTEM OPERATING FACILITY W/ HAZARD WARNING SWITCH
DRIVER'S DOOR CENTRAL LOCKING BUTTON
DRIVER'S SIDE REAR POWER WINDOW SWITCH
FUSE 404
FUSE 9
FUSE BOX
GRY/RED WIRE
HEAD UNIT
HEATING/ AIR CONDITIONING SYSTEM
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT REAR INTERIOR LIGHT
LIGHT OPERATING UNIT
ORG/ WIRE
RED WIRE
RED/YEL WIRE
REFUELING BUTTON
VEHICLE INTERIOR TAILGATE BUTTON
YEL WIRE
YEL/BLU WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> HEATING/ AIR CONDITIONING SYSTEM
