BMW X2 F39 (2017-2023) front passenger's seat backrest heating Wiring diagram
This page shows the only wiring diagram for the component.front passenger's seat backrest heating, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's seat backrest heating (1 of 1)
AIR CONDITIONING
BODY DOMAIN CONTROLLER
BRN WIRE
BUS SIG
COMPUTER DATA LINES SYSTEM
DRIVER THIGH SUPPORT HEATING
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT HEATING ELECTRONICS
DRIVER'S SEAT SURFACE HEATING
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER THIGH SUPPORT HEATING
FRONT PASSENGER'S SEAT BACKREST HEATING
FRONT POWER DISTRIBUTION BOX
FUSE 127
FUSE 128
GRN/VIO WIRE
GRY WIRE
HOT W/ TERMINAL
K-LIN
NCA WIRE
PASSENGER'S SEAT CUSHION HEATING
RED WIRE
RED/GRN WIRE
VIO WIRE
W/ EXTENDABLE THIGH SUPPORT
W/O EXTENDABLE THIGH SUPPORT
WHT WIRE
Go to component -> Heated seats circuit, w/o memory -> FRONT PASSENGER'S SEAT BACKREST HEATING
