BMW X2 F39 (2017-2023) front passenger side seat backrest width adjustment valve block Wiring diagram
This page shows the only wiring diagram for the component.front passenger side seat backrest width adjustment valve block, which is found in the car BMW X2 F39 (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger side seat backrest width adjustment valve block (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT MODULE
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER SIDE SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/ TERMINAL
RED WIRE
W/ LUMBAR SUPPORT
W/O LUMBAR SUPPORT
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Sport seats circuit, w/ electric seat adjustment -> FRONT PASSENGER SIDE SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
