BMW X2 F39 (2017-2023) front passenger lumbar support valve block Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger lumbar support valve block, in which he is found in the car BMW X2 F39 (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger lumbar support valve block (1 of 6)
BODY DOMAIN CONTROLLER
BRN WIRE
FRONT PASSENGER DOOR ENTRY LIGHTING
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FRONT PASSENGER'S DOOR GROUND LIGHT
FRONT PASSENGER'S DOOR TRIM PANEL LIGHTING
FRONT POWER DISTRIBUTION BOX
PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
PASSENGER'S SIDE INTERIOR TRIM LIGHTING
PASSENGER'S SIDE REAR COURTESY LIGHTING
PASSENGER'S SIDE REAR DOOR TRIM PANEL LIGHTING
PASSENGER'S SIDE REAR FOOTWELL LIGHT
PASSENGER'S SIDE REAR INTERIOR TRIM LIGHTING
PASSENGER'S SIDE REAR SILL COURTESY LIGHTING
ROOF FUNCTION CENTER
Go to component -> Ground distribution circuit (4 of 4) -> FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
Wiring diagram front passenger lumbar support valve block (2 of 6)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
RED WIRE
RELAY ENERGIZED
SPORT SEATS CIRCUIT
Go to component -> Lumbar circuit, w/ electric seat adjustment -> FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
Wiring diagram front passenger lumbar support valve block (3 of 6)
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER LUMBAR SUPPORT SWITCH
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/
RED WIRE
RELAY ENERGIZED
SPORT SEATS CIRCUIT
Go to component -> Lumbar circuit, w/o electric seat adjustment -> FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
Wiring diagram front passenger lumbar support valve block (4 of 6)
AUC SENSOR
AUTOMATIC LUGGAGE COMPARTMENT LID ACTUATION
BLK WIRE
BLK/RED WIRE
BOOT LID/ TAILGATE LOCK
BRN WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
CONTROLLER (IDRIVE)
DRIVER'S DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE INTERIOR TRIM LIGHTING
DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
DRIVER'S SIDE REAR INTERIOR TRIM LIGHTING
ELECTRICAL EXHAUST FLAP
ELECTRO- MECHANICAL POWER STEERING
ELECTROCHROMIC INTERIOR MIRROR
FAN BASE PLATE
FROM BODY DOMAIN CONTROLLER (DIAGRAM 2 OF 4)
FROM FUSE 70 (DIAGRAM 2 OF 4)
FRONT INTERIOR LIGHT
FRONT PASSENGER DOOR TRIM PANEL LIGHTING
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT SWITCH
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT POWER DISTRIBUTION BOX
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 53
FUSE 54
FUSE 55
FUSE 56
FUSE 58
FUSE 59
FUSE 60
FUSE 62
FUSE 63
FUSE 65
FUSE 68
FUSE 71
FUSE 75
FUSE 90
FUSE 95
FUSE 96
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
INSTRUMENT PANEL
LEFT FRONT VANITY MIRROR LIGHT
LONGITUDINAL TORQUE DISTRIBUTION
NCA WIRE
OPTIONAL EQUIPMENT SYSTEM
PARKING MANEUVERING ASSISTANT
PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
PASSENGER'S SIDE DASHBOARD DECORATIVE STRIP LIGHTING
PASSENGER'S SIDE INTERIOR TRIM LIGHTING
PASSENGER'S SIDE REAR DOOR TRIM PANEL LIGHTING
PASSENGER'S SIDE REAR INTERIOR TRIM LIGHTING
RADIATOR BLIND DRIVE
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
REAR VIEW CAMERA
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT VANITY MIRROR LIGHT
STEERING COLUMN SWITCH CLUSTER
THIRD ROW SEATS INTERIOR LIGHT
TO BI-STABLE RELAY (DIAGRAM 4 OF 4)
TOUCH BOX
TRAILER SOCKET
USB CHARGING SOCKET 3
USB- HUB
W/ INTERIOR TRIM LIGHTING
W/ TRAILER MODULE
W/ WIRELESS CHARGING STORAGE
W/O TRAILER MODULE
W/O WIRELESS CHARGING STORAGE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
Wiring diagram front passenger lumbar support valve block (5 of 6)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT MODULE
DRIVER'S SEAT PNEUMATIC PUMP
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK
FRONT PASSENGER SIDE SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/ TERMINAL
RED WIRE
W/ LUMBAR SUPPORT
W/O LUMBAR SUPPORT
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Sport seats circuit, w/ electric seat adjustment -> FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
Wiring diagram front passenger lumbar support valve block (6 of 6)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
DRIVER LUMBAR SUPPORT VALVE BLOCK
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT SWITCH
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FRONT POWER DISTRIBUTION BOX
FUSE 73
FUSE 75
HOT W/ TERMINAL
RED WIRE
W/ LUMBAR SUPPORT
W/O LUMBAR SUPPORT
YEL WIRE
YEL/BLU WIRE
YEL/WHT WIRE
Go to component -> Sport seats circuit, w/o electric seat adjustment -> FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK
